Vertical Boring Milling Grinding Machine
* Model: TXM170A, TXM200A, TXM250A;
Characteristic
1) Stepless of spindle turning ,feeding
2) Rotating speed and feed of spindle is free-setup, automatical retuming of spindle can be realized
3) Longitudingal and cross movement of table
4) Complete set of accessories of boring, drilling & reaming and easy exchange
5) Spindle fast centering device
6) Tool measuring device
7) Boring depth control device
8) Table with digital readout for jig borer machine
T/TX/TXM170A/200A/250A
T series: Boring
TX series: Boring and Milling (T series + PLC+milling head φ320 UPGRADE TX series)
TXM series: Boring, milling and grinding
(TX series +Grinding head φ320 +Cooling tank+Protecting panel UPGRADE TXM series
Model | TXM170A | TXM200A | TXM250A | TX170A | TX200A | TX250A |
Max. Boring diameter | Φ170mm | Φ200mm | Φ250mm | Φ170mm | Φ200mm | Φ250mm |
Max. boring depth | 400mm | 500mm | 500mm | 400mm | 500mm | 500mm |
Max. milling area |
400 x 1000mm |
400x1000mm | ||||
Max. grinding area | 480 x 1000mm |
– |
||||
Max. drilling & reaming diameter | Φ30mm |
Φ30mm |
||||
Spindle feed |
120-1200r/min |
120-860r/min | ||||
Feeding of the spindle |
14-900mm/min |
14-900mm/min | ||||
Spindle travel | 700mm | 700mm | ||||
Distance between spindle end face and table |
0-700mm |
0-700mm | ||||
Distance between spindle axis and carriage vertical plane |
375mm |
375mm | ||||
Feeding of the table longitudinal | 32-1350mm/min |
32-1350mm/min |
||||
Rapid moving speed of the table longitudinal travel | 32-1350mm/min |
32-1350mm/min |
||||
Table longitudinal travel | 1500mm | 1500mm | ||||
Table cross travel | 200mm | 200mm | ||||
Table dimension (LxW) | 1250x500mm | 1500x500mm | 1250x500mm | 1500x500mm | ||
Overall dimension (L*W*H) |
260*163*230cm |
260*163*230cm | ||||
Net. weight | 3300kg | 3500kg | 3300kg |
3500kg |
