C9370 brake drum/disc cutting machine is special equipment developed and manufactured by us referred to foreign advanced machine type for maintenance of automobile brake drum/disc. The machine is polish in material use, with consummate process, advanced design, pretty appearance, provided with perfect moulds and clamps for car and light truck suitable for many types of cars. Spindle feed adopts advanced infinitely variable speed design. Feeding capacity can be adjustable within 0.05-0.5 at will, which bring very convenience for you.
Main casting of the machine is made of aluminum alloy material, whole machine weight is very light. Variable speed gear adopts high quality alloy steel 38CrMoAl and made of advanced process through nitrogenation, durability.
|
Model
|
C9350C
|
C9370
|
C9370C
|
|
|
Brake disc
|
Diameter mm
|
178-368
|
178-457
|
178-457
|
|
Thickness mm
|
48
|
48
|
48
|
|
|
Brake drum
|
Diameter mm
|
152-450
|
152-711
|
152-711
|
|
Depth mm
|
160
|
220
|
220
|
|
|
Spindle speed rpm
|
70,88,118
|
70,88,118
|
70,88,118
|
|
|
Cross feeding capacity mm/r
|
0-0.4
|
0.05/0.25
|
0.-0.4
|
|
|
Spindle feeing capaity mm/r
|
0-0.4
|
0.05-0.5
|
0-0.4
|
|
|
Motor power kw
|
0.75
|
0.75
|
0.75
|
|
|
Overall dimensions(L*M*H)mm
|
1200*900*1500
|
1280*1100*1445
|
1280*1100*1445
|
|
|
Weight kg
|
290
|
290
|
290
|
|
|
No.
|
Description
|
Qty.
|
|
1
|
Storage Case Top Tray
|
1
|
|
2
|
Storage Case
|
1
|
|
3
|
Twin-Cutter Assembly
|
1
|
|
4
|
Boring Bar
|
1
|
|
5
|
Hubless Adapter /94mm
|
1
|
|
6
|
Hubless Adapter /94mm
|
1
|
|
7
|
Hubless Adapter /116mm
|
1
|
|
8
|
Hubless Adapter /116mm
|
1
|
|
9
|
Hubless Adapter /146mm
|
1
|
|
10
|
Hubless Adapter /146mm
|
1
|
|
11
|
Centering Cone (30×44mm)
|
1
|
|
12
|
Centering Cone (31×57mm)
|
1
|
|
13
|
Centering Cone (45×70mm)
|
1
|
|
14
|
Double Taper Adapter(34x42mm)
|
1
|
|
15
|
Double Taper Adapter(35x43mm)
|
1
|
|
16
|
Double Taper Adapter(44x52mm)
|
1
|
|
17
|
Double Taper Adapter(52x62mm)
|
1
|
|
18
|
Double Taper Adapter(62x71mm)
|
1
|
|
19
|
Centering Cone (59×75mm)
|
1
|
|
20
|
Centering Cone (66×82mm)
|
1
|
|
21
|
Centering Cone(74x90mm)
|
1
|
|
22
|
Centering Cone(85.8x103mm)
|
1
|
|
23
|
Spacer /6.35mm
|
1
|
|
24
|
Spacer /12.7mm
|
1
|
|
25
|
Spacer /25.4mm
|
1
|
|
26
|
Self Aligning Washer
|
1
|
|
27
|
Arbor Nut /47.6mm
|
1
|
|
28
|
Small Vibration Band/Rotors
|
1
|
|
29
|
Large Vibration Band/Drums
|
1
|
|
30
|
Wrench/Large
|
1
|
|
31
|
Wrench/Small
|
1
|
|
32
|
Cutting Tips
|
6
|
|
33
|
Arbor /φ25.4mm
|
1
|
|
34
|
Arbor Spring
|
1
|
|
35
|
V-Belt /A610 V-Belt
|
1
|
|
36
|
Special Wrench /T9
|
1
|
|
37
|
Main Machine
|
1
|
|
38
|
Lathe Bench(include 20 hooks)
|
1
|
